WS1005E-5T Industrial Switch

5-Port 100Mbps Unmanaged Industrial Ethernet Switch

WS1005E-5T is a 5-Port 100Mbps Unmanaged Industrial Ethernet Switch. This product provides 100Mbps electrical ports and adopts DIN Rail or wall-mounted mounting methods, which meets the needs of different on-site applications.
DIP switches enable loop detection, storm suppression, one-click VLAN, and flow control functions. The hardware features a fanless design and low power consumption, and has passed rigorous tests compliant with industry standards. It can adapt to industrial on-site environments with strict EMC (Electromagnetic Compatibility) requirements, and is widely applicable to industrial sectors such as rail transit, smart cities, safe cities, new energy, and smart manufacturing.

Interface Type: Supports 5 channels of 100Mbps electrical ports

Input Voltage: 12～48VDC or 24VAC

Operating Temperature: Supports -40～75℃

Mounting Method: DIN Rail Mounting

Sample Request Online consulting

Specifications

Standards & Protocols	10Base-T, complies with IEEE 802.3 100Base-TX, complies with IEEE 802.3u Flow Control, complies with IEEE 802.3x
Ports	Electrical Ports: 10/100Base-T(X), RJ45, Full/Half Duplex Mode, Auto-MDI/MDI-X Detection
Indicator Lights	Power Indicator Light, Port Indicator Lights
Switching Characteristics	Transmission Method: Store-and-Forward MAC Address: 2K Backplane Bandwidth: 1G Switching Latency: <10μs
Power Supply	12~48VDC or 24VAC, 3-pin Terminal Block with 5.08mm Spacing Supports Reverse Polarity Protection, Built-in 3.0A Overcurrent Protection
Power Consumption	No-Load Power Consumption: 0.4W@24VDC Full-Load Power Consumption: 1.0W@24VDC
Operating Environment	Operating Temperature: -40~75℃ Storage Temperature: -40~85℃ Relative Humidity: 5%～95% (Non-Condensing)
Mechanical Structure	Housing: IP40 Protection Rating, Metal Housing Mounting: DIN Rail or Wall-Mounted Mounting Dimensions (W×H×D): 28mm×103mm×78mm
Industry Standards	IEC 61000-4-2 (ESD) - Air Discharge: ±8kV - Contact Discharge: ±6kV IEC 61000-4-4 (EFT) - Power Supply: ±2kV - Ethernet Ports: ±1kV IEC 61000-4-5 (Surge) - Power Supply: Common Mode ±2kV, Differential Mode ±1kV - Ethernet Ports: Common Mode ±2kV, Differential Mode ±1kV Shock: IEC 60068-2-27 Free Fall: IEC 60068-2-32 Vibration: IEC 60068-2-6
Certifications	CE, FCC, RoHS
Warranty	5 Years
MTBF	510465 hrs (Mean Time Between Failures)

Product Selection

Model	100Mbps Electrical Ports	Power Supply
WS1005E-5T	5	12~48VDC or 24VAC

Downloads

【Product Specification】WS1005E-5T Product Specification
