WS2028E-4GS-24TIndustrial Switch

WS2028E-4GS-24T Industrial Switch

28-Port Gigabit and Fast Ethernet Mixed Layer 2 Unmanaged Industrial Ethernet Switch

The WS2028E-4GS-24T series is a 28-port Gigabit and Fast Ethernet mixed Layer 2 unmanaged industrial Ethernet switch. There are six models in this series for selection, providing various interfaces such as Fast Ethernet electrical ports, Fast Ethernet optical ports, and Gigabit SFP slots. It supports single or dual power supplies with AC/DC power options and adopts a rack-mounted installation method, which can meet the requirements of different application sites.
The hardware is designed with a fanless, low-power consumption, wide-temperature, and wide-voltage structure. After passing strict tests that meet industry standards, it can adapt to industrial field environments with harsh EMC requirements and can be widely applied in industrial fields such as smart grids, rail transit, smart cities, safe cities, new energy, and intelligent manufacturing.

Interface Type: Supports 4 Gigabit optical ports (SFP slots) and 24 Fast Ethernet optical/electrical selectable ports

Input Voltage: 100 - 240VAC/DC, 24VDC, or 48VDC

Operating Temperature: Supports -40～75℃ Operating Temperature

Mounting Method: 1U Rack-Mounted Installation

Sample Request Online consulting

Specifications

Standards and Protocols

10Base-T, compliant with IEEE 802.3
100Base-TX and 100Base-FX, compliant with IEEE 802.3u
1000Base-X, compliant with IEEE 802.3z

Interfaces

Electrical Ports: 10/100Base-T(X), RJ45, with automatic flow control, full/half-duplex mode, and MDI/MDI-X auto-detection
Optical Ports: 100Base-FX, selectable SC/ST/FC
SFP Slots: 1000Base-X SFP

Indicators

Operating indicator, interface indicator, power indicator

Switching Attributes

Transmission Mode: Store-and-Forward
MAC Address Table: 8K
Buffer: 3Mbit
Backplane Bandwidth: 12.8G
Switching Delay: < 10μs

Power Supply

Supports single or dual power supplies, AC/DC power:

AC Power: 100 - 240VAC/DC, with 8A overcurrent protection
DC Power: 24VDC (12 - 36VDC), polarity-free
DC Power: 48VDC (36 - 48VDC), polarity-free

Power Consumption

Order number	No-load（@220VAC）	Full-load（@220VAC）
WS2028E-4GS-24T	6.9W	12.4W
WS2028E-4GS-24T-2F	8.2W	13.7W
WS2028E-4GS-24T-4F	9.5W	15W
WS2028E-4GS-24T-8F	12.1W	17.6W
WS2028E-4GS-24T-12F	14.7W	20.2W
WS2028E-4GS-24T-16F	17.3W	22.8W

Operating Environment

Operating Temperature: -40 to 75°C
Storage Temperature: -40 to 85°C
Relative Humidity: 5% - 95% (non-condensing)

Mechanical Structure

Enclosure: IP30 protection level, metal enclosure
Installation: 19-inch 1U rack-mounted
Dimensions (Width × Height × Depth): 441.6mm × 44.6mm × 207.9mm

Industry Standards

IEC 61000-4-2 (ESD, Electrostatic Discharge Immunity),Level 4

Air Discharge: ±15kV
Contact Discharge: ±8kV

IEC 61000-4-4 (EFT, Electrical Fast Transient Pulse Immunity),
Level 4

Power Supply: ±4kV
Ethernet Interface: ±2kV
Relay: ±4kV

IEC 61000-4-5 (Surge, Surge Impact Immunity),Level 4

Power Supply: Common Mode ±4kV, Differential Mode±2kV
Ethernet Interface: ±4kV
Relay: Common Mode ±4kV, Differential Mode ±2kV

Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6

Certifications

CE、FCC、RoHS

Warranty

5 years

Product Selection

Order number	Gigabit SFP Slots	Gigabit SFP Slots	Fast Ethernet Electrical Ports	Power Supply (Single or Dual Power Supply Optional)
WS2028E-4GS-24T	4	―	24	100~240VAC/DC 24VDC（12~36VDC）48VDC（36~48VDC）
WS2028E-4GS-24T-2F	4	2	22
WS2028E-4GS-24T-4F	4	4	20
WS2028E-4GS-24T-8F	4	8	16
WS2028E-4GS-24T-12F	4	12	12
WS2028E-4GS-24T-16F	4	16	8

Downloads

【Product Specification】WS2028E-4GS-24T Product Specification
