WS1008E-8T Industrial Switch

8-Port 100Mbps Unmanaged Industrial Ethernet Switch

The WS1008E-8T is an 8-port 100Mbps unmanaged industrial Ethernet switch. This product provides 100Mbps electrical port interfaces and supports DIN rail or wall-mounted installation methods to meet the needs of various application scenarios.
The dial switch enables loop detection, storm suppression, one-touch VLAN, and flow control. The hardware features a fanless, low-power design, passes rigorous industry-standard tests, and is capable of adapting to industrial environments with demanding EMC requirements. It is widely applicable in industrial fields such as rail transit, smart cities, safe cities, new energy, and intelligent manufacturing.

Interface Type: Supports 5 channels of 100Mbps electrical ports

Input Voltage: 12～48VDC or 24VAC

Operating Temperature: Supports -40～75℃

Mounting Method: DIN Rail Mounting

Sample Request Online consulting

Specifications

Standards and protocols	10Base-T, compliant with IEEE 802.3 100Base-TX, compliant with IEEE 802.3u Flow control, compliant with IEEE 802.3x
Interface	Electrical port: 10/100Base-T(X), RJ45, full/half duplex mode, MDI/MDI-X auto-detection
Indicator light	Power indicator light, interface indicator light
Exchange properties	Transmission method: Store and forward MAC address: 2K Backplane bandwidth: 1.6G Switching delay: <10μs
power supply	12~48VDC or 24VAC, 3-core 5.08mm pitch terminal block Supports reverse connection protection and built-in overcurrent protection up to 3.0A.
power consumption	No-load power consumption: 0.5W@24VDC Full load power consumption: 1.4W@24VDC
work environment	Operating temperature: -40~75℃ Storage temperature: -40~85℃ Relative humidity: 5% to 95% (non-condensing)
Mechanical structure	Enclosure: IP40 protection level, metal casing Installation: DIN rail mounting or wall mounting Dimensions (W×H×D): 40.6mm×103mm×78mm
industry standard	IEC 61000-4-2 (ESD) Air discharge: ±8kV Contact discharge: ±6kV IEC 61000-4-4 (EFT) Power Supply: ±2kV Ethernet interface: ±1kV IEC 61000-4-5 (Surge) Power supply: common mode ±2kV, differential mode ±1kV Signal: Common mode ±2kV, differential mode ±1kV Shock: IEC 60068-2-27 Free fall: IEC 60068-2-32 Vibration: IEC 60068-2-6
Certification	CE, FCC, RoHS
Warranty	5 years
MTBF value	540249 hours

Product Selection

Model number	100M Ethernet port	power supply
WS1008E-8T	8	12~48VDC or 24VAC

Downloads

【Product Specification】WS1008E-8T Product Specification
