WS1010M-2GS-8TIndustrial Switch

WS1010M-2GS-8T Industrial Switch

12-port Full Gigabit Layer 2 Managed Industrial Ethernet Switch

The WS1010M-2GS-8T series is a 12-port full gigabit layer 2 managed industrial Ethernet switch. This series provides various interfaces such as gigabit Ethernet ports, gigabit SFP slots, and 2.5G SFP slots. It supports two power supply methods, 48VDC and 220VAC/DC, and adopts DIN rail or wall-mounted installation methods, which can meet the requirements of different application sites.

Interface Type: Supports 2 2.5G SFP slots, 2 Gigabit SFP slots, and 8 Gigabit Ethernet ports

Input Voltage:48VDC, 220VAC/DC

Operating Temperature: Supports -40～75℃ Operating Temperature

Mounting Method: DIN Rail Mounting

Sample Request Online consulting

Specifications

Standards and Protocols	10Base-T, compliant with IEEE 802.3 100Base-TX, compliant with IEEE 802.3u 1000Base-T, compliant with IEEE 802.3ab 1000Base-X, compliant with IEEE 802.3z Flow control, compliant with IEEE 802.3x Spanning Tree, compliant with IEEE 802.1D Rapid Spanning Tree, compliant with IEEE 802.1w Multiple Spanning Tree, compliant with IEEE 802.1s ERPS, compliant with ITU-T G.8032 VLAN, compliant with IEEE 802.1Q CoS, compliant with IEEE 802.1p LLDP, compliant with IEEE 802.1AB LACP, compliant with IEEE 802.3ad
Management Functions	SNMP v1/v2c/v3 for centralized device management, QoS, DHCP Server, DHCP Snooping, DHCP relay, static MAC address, LLDP, storm suppression, user password, login method, file management, log management, port statistics
Security Technologies	User privilege level classification, authentication method configuration, SSH configuration, HTTPS configuration, access control, SNMP, RMON, port restriction control, port security, NAS, ACL, Ethernet services, RADIUS server authentication, TACACS+ server authentication, port alarm, DC power alarm
Switching Functions	802.1Q VLAN, static aggregation, LACP
Unicast/Multicast Technologies	IGMP-Snooping, multicast MAC
Redundancy Technologies	Ring, STP/RSTP/MSTP, ERPS
Fault Diagnosis	Ping, Ping6, cable detection, DDMI, port mirroring
Time Management	NTP, time zone configuration
Interfaces	Gigabit Ethernet ports: 10/100/1000Base-T(X), RJ45, with automatic flow rate control, full/half-duplex mode, and MDI/MDI-X auto-detection Gigabit SFP slots: 100/1000Base-X adaptive or forced mode, SFP slots 2.5G SFP slots: 100/1000/2.5GBase-X adaptive or forced mode, SFP slots Console port: CLI command-line management port (RS-232), RJ45 Alarm port: 6-pin 5.08mm pitch terminal block (2 positions occupied by the relay), supporting 1-way relay alarm output with a current load capacity of 1A@30VDC or 0.3A@125VAC
Indicators	Operating indicator, alarm indicator, power indicator, interface indicator
Switching Attributes	Transmission mode: store-and-forward MAC address: 8K Cache: 4Mbit Backplane bandwidth: 58G Switching delay: <10μs
Power Supply	WS1010M-2GS-8T-2P48： Power input: 12/24/48VDC Connection method: 6-pin 5.08mm pitch terminal block (4 positions for power supply) Number of power supplies: dual power supply redundant backup Connection protection: reverse connection protection Overcurrent protection: 3A WS1010M-2GS-8T-P220： Power input: 220VAC/DC Connection method: 6-pin 5.08mm pitch terminal block (4 positions for power supply)
Power Consumption	WS1010M-2GS-8T-2P48： No-load power consumption: 6.8W@48VDC Full-load power consumption: 8.0W@48VDC
Operating Environment	Operating temperature: -40°C to 75°C Storage temperature: -40°C to 85°C Relative humidity: 5% - 95% (non-condensing)
Mechanical Structure	Enclosure: IP40 protection level, metal enclosure Installation: DIN rail or wall-mounted installation Weight: ≤0.78kg Dimensions (width × height × depth): 53mm × 138mm × 110mm
Industry Standards	IEC 61000-4-2 (ESD, Electrostatic Discharge Immunity), Level 4 Air discharge: ±15kv Contact discharge: ±8kv IEC 61000-4-4 (EFT, Electrical Fast Transient Pulse Immunity), Level 4 Power supply: ±4kv Ethernet port:: ±2kv IEC 61000-4-5 (Surge, Surge Impact Immunity), Level 4 Power supply: common mode ±4kv, differential mode±2kv Ethernet port: common mode ±4kv, differential mode±2kv Shock: IEC 60068-2-27 Free fall: IEC 60068-2-32 Vibration: IEC 60068-2-6
Certifications	CE, FCC, RoHS
Warranty	5 years

Product Selection

Order number	Gigabit RJ45	2.5G SFP Slots	Gigabit SFP Slots	Power Supply
WS1010M-2GS-8T-2P48	8	2	2	12/24/48VDC
WS1010M-2GS-8T-P220	8	2	2	220VAC/DC

Downloads

【Product Specification】WS1010M-2GS-8T Product Specification
